ATC LOUDSPEAKERS SCM 20 P PRO MKII

ATC SCM20P PRO MKII PASSIVES

Moniteur passif 2 voies pour champ proche

• Haut-Parleur ATC 150mm/6”; super linéaire pour les médiums et les graves
• Tweeter breveté ATC 25 mm/1” à double suspension

• Compact very high performance passive 2-way studio monitor
• Ideally suited to:

– critical near-field listening applications in all control rooms
– LCR surround monitoring in small-to-medium control rooms
– surround channels in medium-to-large control rooms

• Proprietary ATC 150mm/6” Super Linear Mid/Bass Driver
• Proprietary ATC 25mm/1” Dual Suspension ‘S-Spec’ Tweeter
• Wide, even dispersion
• SCM20PSL Pro
  Drivers: LF 6.5”/150mm Super Linear, HF 1”/25mm Dual-Suspension ‘S-Spec’ Tweeter
  Amplitude linearity : 80Hz – 20kHz (+/-2dB)
  Cut-off frequencies : 55Hz – 25kHz (-6dB freestanding)
  Dispersion :+/-80° coherent horizontal, +/-10° coherent vertical
  Maximum continuous SPL : 108dB (per pair @ 1m)
  Crossover frequency : 2.5kHz
  Recommended Amplifier Power: 75 to 300 Watts
  Nominal Impedance : 8 Ohm
  Connectors : 2 x Pairs Binding Posts/4mm Plugs – Bi-Wireable
  Cabinet Dimensions (HxWxD) : 450x250x294mm (17.7″x9.8″x11.6″)
  Weight : 18kg/39.7lbs (per cabinet)
